SKF 61803-2RS1 Bearing | Sealed Deep Groove Ball Bearing
SKF 61803-2RS1 Bearing | Sealed Deep Groove Ball Bearing

SKF 61803-2RS1 Rubber Sealed Single Row Deep Groove Ball Bearing 17x26x5mm

Equivalent to 6803-2RS

Rubber Sealed Deep Groove Ball Bearings are widely used bearings in many industries and applications. They are valued for their great durability, flexibility and maintenance free design. These Bearings are Built with rubber seals on the two sides, pressed into the outer raceway and in contact with the inner ring so they efficiently are protected from dust, dirt, moisture and retain the factory filled grease. This offers smooth operation, high speed capability and long life service. Seals can be removed in applications where one sided sealing is required. They are Ideal for home appliances, electric motors, industrial machinery and automotive. These bearings are simple to use, cost efficient and offer long life performance in harsh conditions.

61803-2RS1 SKF
£9.79
VAT excluded

Description

SKF Deep Groove Ball Bearing 17x26x5mm-61803-2RS1

Select this SKF ball bearing for improved performance and moisture and dust resistance. Maintenance and downtime are decreased because there is very little chance of lubricant leaking from the sealed component.  Because of its synthetic rubber seals' exceptional resistance to chemicals and moisture, the bearing lasts a long time in demanding industrial settings. Due to its low vibration and minimal friction, this bearing is well suited for applications requiring high rotating speeds.

Features

Seals strengthened with steel for added durability and strength

It is appropriate for a wide range of operational settings due to its wide operating temperature range of -40°C to +120°C.

Its capacity to support both axial and radial loads increases its usage and usefulness.

Common Applications

Turbines and wind power generating

Industrial blowers and pumps

What are the benefits of a bearing that produces less noise?

Electric motors benefit greatly from reduced-noise bearings, such as this one from SKF, which help ensure the motor operates as quietly as possible. Because operators can more readily assess and pinpoint the issue producing the noise, lower bearing noise also aids in exposing flaws in other components.

Product Details

Inner Diameter
17mm
Outer Diameter
26mm
Width
5mm
Closure Type
Rubber Sealed
Clearance
Normal Radial Clearance
Material
Bearing Steel
Dynamic Load
2.03kN
Static load
1.27kN
Cage
Sheet Steel Cage
Bore
Cylindrical Bore
Weight
0.009 kg
Country of Origin
Japan
Temperature Range
-40 to +120 °C
Ball Rows
Single Row
SKF performance class
Explorer
Ball Bearing Type
Single Row Deep Groove Ball Bearing
Partial Bearing Code
61803
Model Number p
618032RS
87 Items
7316577611536
7316577611536
