SKF 6000/C3 Open Deep Groove Ball Bearing
The SKF 6000/C3 is an open single row deep groove ball bearing designed for smooth rotation and efficient shaft support. It accommodates radial loads and axial loads in both directions while maintaining low friction. Its increased internal clearance makes it suitable for compact rotating equipment where C3 clearance is specified.
Design and Construction
The SKF 6000/C3 features deep raceway grooves and a single row of steel balls guided by a sheet metal cage. Its bearing steel construction provides strength and supports efficient load distribution under suitable operating conditions. With dimensions of 10x26x8mm, the bearing offers compact shaft support for machinery requiring the standard 6000 bearing size.
C3 Internal Clearance and Open Design
The bearing features **C3 radial internal clearance**, providing greater clearance than a bearing with normal internal clearance. This helps compensate for reductions in operating clearance caused by interference fits and temperature differences between the bearing rings. Its open design without seals or shields allows direct grease or oil lubrication. Suitable external sealing may be required to protect the rolling elements against contamination and prevent lubricant loss.
Applications
The SKF 6000/C3 can be considered for rotating equipment where its dimensions and increased internal clearance meet the operating requirements.
Small electric motors
Industrial fans and ventilation equipment
Compact pumps
Mechanical drive assemblies
Agricultural machinery
General industrial equipment
Benefits
The SKF 6000/C3 open deep groove ball bearing provides several practical advantages.
Low Friction: Supports smooth rotation while helping reduce mechanical energy losses.
C3 Internal Clearance: Helps accommodate reductions in operating clearance caused by shaft fits and temperature differences.
Combined Load Support: Accommodates radial loads and axial loads in both directions.
Compact Construction: Provides effective shaft support within the standard 6000 bearing dimensions.
High Speed Capability: Its deep groove design supports efficient operation at relatively high rotational speeds.
Flexible Lubrication: Open construction allows direct grease or oil lubrication.
Bearing Selection
Before purchasing, confirm that the 10x26x8mm dimensions and C3 internal clearance match your equipment specifications. Operating loads and speeds should be checked alongside shaft and housing fits. Lubrication and contamination exposure should also be considered. If normal internal clearance or integrated sealing is required, a different SKF 6000 variant may be more appropriate.
